ITC-HSN: 84716090
Min Order Qty 1
Accept Small Orders
Fulfilment Capacity (Per Month): 25 pieces/month
Product not available
The 3Mâ„¢ QS1000 Quick Scan Reader inspects and images Machine Readable Travel Documents (MRTDs) in a variety of market segments.
Applications that are focused on data capture opportunities in hotels, casinos, liquor stores, bars, rental car companies and the transportation markets.
Key Features & Functionality:
Multiple document reading and imaging in 24-bit color
400 DPI high resolution imaging
Optical document analysis in border management commercial markets
Multiple wavelength illumination – Visible and IR
OCR data capture
Complete access to OCR data and images captured via Software Development Kit (SDK)
Enables images to be accessed as BMP, PNG or JPEG format
Compatible with Windows® 2000-SP4, XP or Windows Vista®
USB 2.0 high speed compatible
Auto-triggering of document capture - presence of document is automatically detected
No moving parts and comes with an IP50 rating for dust ingress protection
Comprehensive Software Features
Flexible software interface allows host application to select which illumination sources to use, image type, image compression, photo extraction etc.
Simple high level API for quick program development or detailed low level API for fine control of all reader functions.
SDK provides full configuration API
Contactless or contact IC reading for ePassports (LDS 1.7) including Active and Passive authentication, Basic Access Control and Extended Access Control.
Full SDK including DLLs and demonstration/support programs. Support for Visual C++®, Visual Basic®, C++ Builder®, Java, Delphi®.
Reading Capability
ICAO compliant documents in near infrared (IR) per ICAO 9303 specification Parts 1-4
1D barcodes (2 of 5 interleaved, Code 128, and Code 39, EAN 8 And EAN 13) - Optional
2D barcodes (PDF 417, QR, DataMatrixâ„¢ and Aztec formats) from paper documents and most mobile devices - Optional
System Specifications
Illumination: Near IR: B900, 880nm, +/-5%,white Visible: 430-700nm
Resolution: Sensor: 3.1 Megapixels, CMOS, RGB 24 bit color system, Standard 400 DPI image resolution
Power: Input Voltage - 100 - 240 VAC +/- 10%,Frequency: 47 - 63 Hz, Detachable IEC-320-C14 AC mains power cable
Power consumption: < 7 Watts at 12-volts DC
Connectivity: Locking 4 pin connector
Status Indicators: Red - Read Error LED, Green - Valid Read LED, Yellow - Busy LED, Blue - Ready LED
Physical characteristics
Weight: < 1 kg or 2.2 lbs
Dimensions: length 19.0 cm width 16.2cm Height 15.7cm
Dimensions with Card Option: 20.4cm width 16.2cm Height 15.7cm
Environmental
Temperature: 0º to 40ºC operating; -20º to 50ºC storage
Humidity: 20 to 80% (R.H. non-condensing)
Security
Keystone lock
