Model LE-DMM

Application Generator Control Panels ,Distributive Control panels ,Load Analysis Systems, Electrical Control Panels

Brand Black Currant

Features:

State of the Art 32 Bit Micro controller based Design Ultra bright 3 line 3 digits LED Display Shows phase wise accurate measurement True

RMS measurements96 x 96 mm Housing Site Programmable of CT Ratio• Accuracy of 0.5% 3 touch switch for adjustments, Password Protection

Technical specifications: Auxiliary supply: 90VAC to 270VAC

Input: 3 phase, 4 Wire

Input Current Range: 5A Max

Input Voltage Range: 100 VAC to 600V AC

Frequency Measurement: 30 Hz to 75Hz

Communication Options: Optional RS 485- MODBUS protocol Burden on Line: 0.05 VA per phase (Maximum) Burden on Aux: 2 VA (Maximum)CT Primary: 5 to 5000 Programmable

Resolution: 0.01, 0.1, 1 (depending on Auto range).

Measurement type: True RMS Measurement Display Scrolling: Auto / Fixed screen

Display parameters:

3 Phase Voltage (L-L, L-N) 3 Phase Current, Frequency Power Factor per phase Power per phase, system power Active and Apparent power.

Additional Information:

Item Code: LE-DMM.
