Depth : 8" dia bore holes to a depth of 600mtr(2500ft) using 5.5" drill rod

           10" dia bore holes to a depth of 450mtr (1500ft) using 5.5" drill rod

Prime mover : Separate deck engine

Mast : 10" or 12" - 'C' channel box type structure

max capacity- 42tons(92594 lbs)

Height - 9 mtr (30 ft)

Rod handling 4.5 mtr (15ft)

Casing pipe 6 mtr (20 ft)

Rod changer with auxiliary winch: Manually operated three rod changer with 2000kgs capacity pull up winch to carry drill pipes, hammer & other tools

Break out: To open the drill joints hydraulic break out cylinder of 300mm stroke will be provided

Hydraulic system: Hydraulic pressure : 246 kgs/cm2 (3500psi)

Pull up speed : 30.5 mtr / min (100 ft / min)

Pull up force : 18410kgs (40500 lbs)

Pull down force : 12635kgs (27800 lbs)

Pull down speed : 44 mtr/min (147 ft / min

Reeving ration: 1:3

Rotary head: Maximum torque 146kg-mtrs(12740 inch-lbs)

rotary head speed: 0 To 160

Water injection pump: 150 lpm water pump driven by hydraulic motor

Optional attachment: Hydraulic motor drive mud pump, welding machine, diesel or oil filling pump

Suitable compressor: 1100cfm@300psi; 1200cfm@415psi

Jack: Four hydraulic leveling jack for proper leveling drill point with separate lever
