ITC-HSN: 843041
Min Order Qty 1
Accept Small Orders
Fulfilment Capacity (Per Month): 1 pieces/month
Product not available
SPECIFICATIONS:
| Drilling Diameter | 8"-17"(203mm-432mm) |
| Drilling Depth | 2650 Feet (810 Mtrs) |
| Formation | Soft / Medium / Hard |
| Prime mover of hyd. Powerpack | Truck Mounted Rig with Power from DECK ENGINE |
| Carrier/Mounting | Separate Truck for Mounting of Rig & Air Compressor |
| Compressor | Suitable Compressor- ELGI / ATLAS COPCO / IR |
| Maximum Operating Pressure | 210 Kg/Cm2 |
| Hydraulic Oil Tank Capacity | 800 Ltrs |
| Mast Capacity (WT) | 40 Tons |
| Mast Capacity (Rod Handling) | 20 Feet (6.1 Mtrs) |
| Pull Up Speed | 20 Mtrs/Min |
| Pull Up Force | 20940 Kgfm |
| Pull Down Force | 10680 Kgfm |
| Rotation speed | 0-100RPM |
| Rotary Head TORQUE | 490 Kgm |
| Rod changer | Manually Operated Rod Changer |
| Note : Due to continuous development all the above specifications are subject to change |
ASQUARE - Water Well Drilling Rigs Manufacturers
Rajkot, India
Business Operations: Manufacturer, Merchant
Contact us for
Description:
| Dth Drilling Rig Automatic 700 Meter Capacity |
| 10'' Channel heavy duty mast |
| Milled ms pully & usha martin wire rope |
| Rotaryhead steel cast body with grining and imported bearings |
| Hydraulic motor - 315 [OMT] - 2 No's |
| 180MM hydraulic feed cylinder |
| PTO gear with steelcast body with grining and imported bearings |
| Casapa italy pump [65 galan] - 2 No's |
| Yuken pump - 2 No's |
| Commercial CM2 - 2 No's |
| Hydro controll 6 liver valve - 2 No's |
| Hydro controll check valve - 6 No's |
| Hydraulic rubber pipes[ Gats company brand] |
| Hydraulic accembly, micro, fordial, hydraulic oil meter, flow controll valve |
| 10'' Channel rig chassis with 6'' channel support |
| 5Mm checker's plate plateform |
| 140MM leveling jack - 4 No's |
| 160MM MRC jack - 1 No's |
| Breackout spanner with hydraulic jack |
| Wrinch gear with suitable motor |
| Hp hydraulic oil - 500 leter |
| Oil tank, Diesel tank |
| Hammer stand, Tool box |
| Color & Redium |
| Established in: | 2019 |
| Bussiness Type: | Partnership |
| Bussiness Type: | Manufacturer, Merchant |
| MSME: | Yes |
| Countries exporting to: | Congo The Democratic Republic Of The, Kenya, Malawi, Mozambique, Oman, Tanzania |
| Export Turnover (3 years): | US$100,000 - US$500,000 |
| Countries would like to export to: | Algeria, Angola, Botswana, Burkina Faso, Central African Republic, Cote D'Ivoire (Ivory Coast), Ethiopia, Gabon, Ghana, Kenya, Malawi, Mali, Morocco, Mozambique, Namibia, Niger, Nigeria, Oman, Qatar, Saudi Arabia, Senegal, Sierra Leone, Somalia, South Africa, South Sudan, Sudan, Tanzania, Turkey, Uganda, United Arab Emirates, Zambia, Zimbabwe |
| No of employees: | 1-10 |
