ITC-HSN: 761699
Min Order Qty 1
Product not available
drive & steering, axle expansion & retraction in narrow space at will;
● 40% increase in action efficiency compare with equivalent products in the industry;
● Cat3 safety architecture, full redundancy of electronic control software & hardware;
● Jib with 230°amplitude, which can be hooked back to suit standard container transport;
● Equipped with 360V150-180Ah modular high-voltage power battery, with a universal range extender, which charges the battery when there is no external power supply.
Contact us for
Max. Working Height 44.44m/146ft
Max. Platform Height 42.44m/139ft 3in
Max. Operating Range(+0.6m) 25.60m/83ft 12in
Max. Platform Range 25.00m/82ft
Max. Up And Over Clearance/
Max. Down Probing Depth/
Overall Length(Stowed) 17.00m/55ft 9in
Overall Width(Axle Expanded) 4.17m/13ft 8in
Overall Width(Axle Retracted) 2.44m/8ft
Overall Height(Stowed) 2.83m/9ft 3in
Transport Size(Length×Width×Hight) 11.92m×2.44m×2.83m/39ft 2in×8ft×9ft 3in
Platform Size(Length×Width) 2.44m×0.91m/8ft×2ft 11in
Platform Height/
Turntable Tailswing(Axle Expanded) 1.39m/4ft 7in
Turntable Tailswing(Axle Retracted) 2.28m/7ft 6in
Ground Clearance(Stowed/Raised) 0.40m/1ft 4in
Wheelbase(Axle Expanded) 4.07m/13ft 4in
Wheelbase(Axle Retracted) 4.27m/14ft
| Established in: | 1974 |
| Bussiness Type: | Private Limited |
| Bussiness Type: | Manufacturer |
| MSME: | Yes |
| Countries exporting to: | Bangladesh, Sri Lanka, South Africa |
| Export Turnover (3 years): | US$50,000 to US$100,000 |
| Countries would like to export to: | Kuwait, Saudi Arabia, United Arab Emirates |
| No of employees: | 501-1000 |
