Shoulder Nut Eye Bolt - Installation for Angular loading

The threaded shank must protrude through the load sufficiently to allow full engagement of the nut.

If the eye bolt protrudes so far through the load that the nut cannot be tightened securely against the load, use properly sized washers to take up the extra space

Between The Nut And The Load

Place washers or spacers between nut and load so that when the nut is tightened securely, the shoulder is secured flush against the load surface.

Forged Eye Bolt Warning & Applications

Important Safety Information - Read & Follow

Inspection / Maintenance Safety

Never use eye bolt that shows signs of wear or damage

Never use eye bolt if eye or shank is bent or elongated.

Always be sure threads on shank and receiving holes are clean

Never machine, grind, or cut eye bolt.

Assembly Safety

Never exceed load limits specified in Table I

Never use regular nut eye bolts for angular lifts.

Always use shoulder nut eye bolts (or machinery eye bolts) for angular lifts.

For angular lifts, adjust working load as follows:

Never undercut an eye bolt to seat shoulder against the load.

Always countersink receiving hole or use washers to seat shoulder.

Always screw eye bolt down completely for proper seating.

Always tighten nuts securely against the load.

Shoulder Nut Eye Bolt - Installation for Angular loading

Operating Safety

Always stand clear of load

Never lift load with steady, even pull - do not jerk.

Always apply load to eye bolt in the plane of the eye, not at an angle

Never exceed the capacity of the eye bolt.

When using lifting slings of two or more legs, make sure the loads in the legs are calculated using the angle from the vertical to the leg and properly size the shoulder nut or machinery eye bolt for the angular load.

Warnings

Loads may slip or fall if proper eye bolt assembly and lifting procedures are not used.

A falling load can seriously injure or kill. Read,& understand all instructions and diagrams. Follow all eye bolt safety information provided here.
