These compact Tube Furnaces with integrated control system can be used universally for many processes . Equipped with a standard working tube of C 530 ceramic and two fiber plugs, these tube furnaces have an unbeatable price/performance ratio.

• Tmax 1200°C or 1300°C
• Single-zoned design as standard
• Dual shell housing made of sheets of textured stainless steel
• Only fiber materials are used which are not classified as carcinogenic according to TRGS 905, class 1 or class 2
• Outer tube diameter of 50mm to 170mm, heated length from 250mm to 1000mm
• Working tube of C 530 ceramic including two fiber plugs, as standard equipment
• Tmax 1200°C: Type N thermocouple
• Tmax 1300°C: Type S thermocouple
• Solid state relays provide for lownoise operation
• Defined application within the constraints of the operating instructions
• NTLog Basic of Nabertherm controller: recording of process data with USB-flash drive

Additional equipment

• Over-temperature limiter with adjustable cutout temperature for thermal protection class 2 in accordance with EN 60519-2 as temperaturelimiter to protect the furnace and load
• Charge control with temperature measurement in the working tube and in the furnace chamber outside the tube
• Three-zoned design (heated length from 500mm)
• Working tubes
• Gas supply systems for protective gas or vacuum operation
