Patient type: Adult, Pediatric infant (= 5kg)
Ventilation modes: A/C(V), A/C(P), SIMV(V) + PS, SIMV(P) + PS, Spont, PRVC
Tidal Volume: 20 - 2000 ml
Ventilation frequency: 1 - 100 bpm (increment : 1 bpm)
Inspiration time: 0.2 - 10S (increment : 0.1S)
FiO:2 21% - 100%
Flow trigger: 0.5 - 20 L/Min
Pressure trigger: -20 - 0 cm H20
Pressure control: 5 - 70 cm H20
Pressure support: 5 - 70 cm H20
Electronic PEEP: 0 - 40 cm H20
Nebulizer: 30 minutes
Direct access function: 100% 02 2 min, Inspiration hold, Expiration hold, Manual, Freeze, Nebulizer (optional)
Monitoring: Volume: VTI, VTE, MV, Mvspont
Waveform: Pressure: Ppeak, PEEP, Pplat, Pmean, Pmin, PEEP Freq, Fspont, I:E, FiO2, Compliance, Resistance P-T, F-T, V-T
Loop: P-V, F-P, F-V
System Log: 500 events (setting and alarm)
Alarm: Audio and visual alarms with three levels
Volumes: VTE high/Iow MV high/Iow
Pressure: Paw high/Iow Apnea Continuous high airway pressure O2 supply pressure high/Iow Air supply pressure high/low Freq high/low, FiO2 high/low
Power: AC power failure, Low battery power, Exhausted battery failure
