Sparkler Filter Different Sizes( 8 inches to 24 inches in diameter)

ITC-HSN: 84798970

5845.94/cm

Min Order Qty 1 cm

Accept Small Orders

  • Product not available

We are the manufactures and exporters of best quality Sparkler filter machines based out of Mumbai.



Specifications available :

  • Capacity (Dia In Inch) - 8,14, 18, 24 and 33 with Suitable No. of Plates.
  • Accessories - Pressure Gauge, Safety Valve, Air Vent, Ball Valves, Sampling Valve, Filter Media (PP/ Cellulose) and Suitable Elastomer Silicon/ PTFE/ EPDM/ Viton.
  • cGMP Model and Design as per ASME guidelines.
  • MOC- SS304 / SS316 / SS316L / HASTELLOY / PP
  • Suitable Model to be suggested as per the actual requirements of Holding Capacity and Filtration area.
  • Various types of Coating for Wetted Parts like - HALAR/ ETFE/ PFA/ PVDF/ PP (Food Grade) and Hastelloy for Friticon Parts etc.
  • Available Lining - PVDF, PP and Teflon.
  • Options for Various range of Pumps (KSB, Antico, QVC, Flurolined, Sulzer, Johnson, Alfa Laval, or as per requirements).
  • Qualification Documents - IQ, DQ, OQ and FAT Protocol.

Business Operations: Manufacturer

Contact us for


By clicking on ‘Send Trade Enquiry’, you agree to our terms & condition and user policies

About Sparkler Filter:


The operation of the sparkler filter press is to filter the impure liquid. Arriving on top of each horizontal plate with increasing pressure, the filter media holds back the impurities and allows the filter to pass through Centre by interlocking cups, which takes the filtrate to the outlet of the filter.


NB:- Spares items also available like Gasket, Tie Rod, Centre Rod, Valves, Castor Wheels, Filter Media, Mechanical Seal, Pump, and Motor etc.

Established in: 2020
Bussiness Type: Private Limited
Bussiness Type: Manufacturer
MSME: Yes
Countries exporting to: Ecuador, Jordan, Nepal, Nigeria
Export Turnover (3 years): US$50,000 to US$100,000
Countries would like to export to: Argentina, Brazil, Bulgaria, Croatia (Hrvatska), Czech Republic, Ecuador, Egypt, Israel, Jordan, Kazakhstan, Mauritius, Mexico, Nepal, Nigeria, Sri Lanka, Trinidad And Tobago, Turkey, Turkmenistan, Uzbekistan
No of employees: 11-30
