Product Description

Tomato Seed Extraction Machine is developed by our company to extract the seeds from ripened Tomato fruit. The fruits are fed in the hopper which feds it through auger to crusher assembly. Fruit is crushed and upper pulp is separated by rotating blade in upper drum from juice whit seeds. The juice with seed passes through SS perforated round sheet in to lower drum. Here also there is round SS perforated sheet to separate the juice and seed from each other.

Machine has adjustments for crusher depending upon fruit size to crush it perfectly.

All main contact parts in SS with heavy supporting structure and separate mounting structure for 5 HP Hand operated Diesel Engine. Foundation for electrical motor is also provided on MS structure for operating machine by electrical motor in case of availability of electrical power. Electrical motor can be provided if required at separate additional cost.

Cleaning of machine is also very easy. Just open upper and lower drum outer covers. Open side Flanges fixed in 3 nuts for upper and lower drum. Machine is ready for cleaning. Pour water from hopper end and clean the machine.

Capacity- 2 to 3 Ton per hour.

Features

• Consistency in quality of output
• High Output of 2 to 2.5 Tons per hour
• Robust design
• Easy internal machine cleaning
• Low Maintenance
• With Diesel Engine to avoid breakdown due to non availability of electricity
