LJE&EC manufacture Coal nozzle, Coal nozzle tips and complete Coal Compartment assemblies for different sizes of fossil fuel fired boilers.

LJE&EC Parts are considered superior due to higher reliability and high fuel load flexibility

The coal compartment assembly is connected to the fuel pipe at the wind box front directing fuel and transport air through the windbox into the furnace.

Major components of the compartment assembly include the stationary Coal Nozzle and tilting Nozzle Tip and seal plate

Our Parts are manufactured from super high heat resistant alloys to ensure longer life.

The Coal nozzles are either of fabricated design or the precision machined from SG iron castings to ASTM A536 GR 65 grade.

Standard coal nozzle of cast ductile iron ceramic-lined Coal Nozzle

The Coal Nozzle Tip which directs fuel flow is the last wear component in the coal delivery system. Because of its high temperature and harsh operating conditions they are subjected to.

Coal Nozzle Tips are manufactured from SS-310 plates are susceptible to high wear and severe damage, as this is expected to perform under extreme conditions
