ITC-HSN: 84879000
Min Order Qty 4 NOS (Numbers)
Accept Small Orders
Fulfilment Capacity (Per Month): 98 NOS (Numbers)/month
Product not available
Dynemech Jackup mounts DJM-2 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.
Dia D(mm):- 90mm To 160mm
Height H(mm):-49mm To 49mm
G(mm): M20x2.5 Thread Length:38mm To M20x2.5mm
Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm)
Load Capacity:850Kg/pc To 2500Kg/pc Levelling Adjustment(mm):18 mm To 18 mm
Natural Frequency Range Hz: 18(Hz) To 18(Hz)
Coeff. of Friction: 0.9 To 0.9
Weight ( Kg.):1.5 Kgs To 5 Kgs
Working Temp Range: -16 to 90
https://vibrationmountsindia.com/
Contact us for
Dynemech Jackup mounts DJM-2 provides isolation solutions for various machines and mounting conditions. The Dynemech Jackup mounts also provides for high machine leveling capabilities. These Jackup mounts provide high load capacity and best level stability. The bottom design provides for non-skid properties for the Jackup mount. The Jackup mount also provide very good passive vibration isolation.
Dia D(mm):- 90mm To 160mm Height H(mm):-49mm To 49mm G(mm): M20x2.5 Thread Length:38mm To M20x2.5mm Thread Length:38mm HEX SW(mm): 46(mm) To 62(mm) Load Capacity:850Kg/pc To 2500Kg/pc Levelling Adjustment(mm):18 mm To 18 mm Natural Frequency Range Hz: 18(Hz) To 18(Hz) Coeff. of Friction: 0.9 To 0.9 Weight ( Kg.):1.5 Kgs To 5 Kgs
Working Temp Range: -16 to 90
Material : Cast Iron, Rubber
Colour: Red
Price-2270
https://vibrationmountsindia.com/
| Established in: | 2000 |
| Bussiness Type: | Private Limited |
| Bussiness Type: | Manufacturer |
| MSME: | Yes |
| Countries exporting to: | Russia, China, United States, United Arab Emirates, United Kingdom, Australia, Canada, Bangladesh, Nepal, Afghanistan |
| Export Turnover (3 years): | Less than US$10,000 |
| Certifications: | IEC CERTIFICATE |
| Countries would like to export to: | Turkey, United States, United Arab Emirates, Philippines, Poland, Portugal, Russia, France, Mauritius, Maldives |
| No of employees: | 51-100 |
