ITC-HSN: 843041
Min Order Qty 1 NOS (Numbers)
Accept Small Orders
Fulfilment Capacity (Per Month): 3 NOS (Numbers)/month
Product not available
PILLING RIG
DIAMETER : 850MM @ AUGER ( IN DRY FORMATION)
1200MM @ WATER SYSTEM ( WITH WATER)
DEPTH: BY AUGER - 18 METER
BY WATER - 35 METER
DHIRAJ RIGS PVT LTD - Manufacturer & Exporter
Kalol, India
Business Operations: Manufacturer, Merchant
Contact us for
Depth: 4 1/2" dia bore holes to a depth of 100mtr(330ft) using 3" drill rod
6 1/2" and 8" dia in steps bore holes to a depth of 80mtr(240ft) using 3" drill rod
10" dia bore holes to a depth of 50mtr (150ft) using 4.5" drill rod
Prime mover: Through PTO drive from tractor engine
Mast: 6" 'C' channel structure
Max capacity- 8tons(17600lbs)
Height - 4.5 mtr (15ft)
Rod handling 3 mtr (10ft)
Hydraulic system: Hydraulic pressure : 140kg/cm2(2000psi)
Pull up speed : 6.9 mtr / min (23ft / min)
Pull up force : 3000kg (6600 lbs)
Pull down force : 2000kg (4400 lbs)
Pull down speed : 10.5 mtr/min (34ft / min)
Reeving ration: 1:02
Rotary head: Maximum torque 146kg-mtrs(12740 inch-lbs)
Rotary head speed: 0 To 100
Water injection pump: 80lpm water pump driven by hydraulic motor
Optional attachment: Hydraulic motor drive mud pump
Suitable compressor: 450cfm@175psi; 600cfm@200psi ; 900cfm@200psi
Jack: Four hydraulic leveling jack for proper leveling drill point with separate lever
| Established in: | 2011 |
| Bussiness Type: | Private Limited |
| Bussiness Type: | Manufacturer, Merchant |
| MSME: | Yes |
| Countries exporting to: | Somalia, Kenya, Algeria, Angola, Nigeria, Niger, Ethiopia, Burkina Faso, Cameroon, Central African Republic |
| Export Turnover (3 years): | US$500,000 - US$1,000,000 |
| Countries would like to export to: | Senegal, Morocco, Gambia The, Botswana, Egypt, Oman, Saudi Arabia, United States, United Kingdom, United Arab Emirates |
| No of employees: | 31-50 |
